MJF100 Features:

1.     Dual LED four digits display

2.     Counting range”-1999~9999.setting range 1-9999

3.     Dry contact input,NPN transistor input,Quadrature 90oinput

4.     Input frequency from 1 to max 5000HZ and configurable

5.     Normal counting/batch counting/totalizing counting

6.     Various reset mode and relay reset delay function

7.     12 VDC 100 mA auxiliary power source for sensor

8.     Up or down counting mode selectable

9.     85~265 Vac or 24 VAC/VDC power source

10.   Power failure retention on/off configurable

11.   Decimal point display,no decimals to max 3 decimals

12.   Relay reset delay range 0.01 sec~99.99 sec

13.   Multiplier available for easy meter counting application

14.   Quadrature input for encoders

15.   Optional features:

      RS485 Modbus RTU communication

      OP2/OP3/OP4 OUTPUT optional

      24VDC/AC source optional,standard source is 85-265VAC
